TOKYO—Toshiba Electronic Devices & Storage Corporation (“Toshiba”) has launched an H-bridge motor driver, “TC78H660FNG,” housed in a TSSOP16 package with a widely used pin-assignment. It is Toshiba’s latest addition to its line-up of drivers for brushed DC motors and stepping motors for applications that include mobile devices and home appliances.
Toshiba’s new-generation DMOS process allows TC78H660FNG to achieve a low ON resistance of 0.48Ω at its maximum rating of 18V/2.0A,[1] and reduces heat generation compared with Toshiba’s current products.
The new driver has a regulator for driving internal circuits, and can drive a motor with a single power supply ranging from 2.5V to 16V. Its wide range of applications include mobile devices powered by a 3.7V lithium-ion battery, 5V USB powered devices, and 12V system devices for home appliances. It also supports a low 1.8V interface.
Features
- Single power drive, simple PWM control
- Low ON resistance reduces heat generation compared with Toshiba’s current products.
(Ron=0.48Ω (upper + lower: typ.) @VM=12V, Ta = 25°C) - Low current consumption (ultra-low standby current: 0.1μA or less ＠Ta=25°C)
Applications
Battery-powered mobile devices, including robots and toys; home appliances including refrigerators, smart meters, etc.
For more information about the new product, visit:
For more information about Toshiba’s motor driver IC line-up, visit:
Notes:
[1] Actual motor drive current depends on the use environment and such factors as ambient temperature and power supply voltage.
