Epson Begins Volume Production of S1D13L04 Display Controller for High-Resolution Color TFT Panels

Seiko Epson Corporation (TSE: 6724, “Epson”) has begun volume production of S1D13L04 display controllers that support color TFT^*1 liquid crystal display panels with up to XGA resolution. Epson plans to produce 20,000 units per month.

Manufacturers are increasingly demanding color TFT liquid crystal display panels for use in industrial equipment and medical instrument control panels because of their good visibility and rendering capability. Moreover, as prices for color TFT LCDs fall, they are adopting larger panel sizes and higher resolutions (e.g., XGA). In addition, low-power devices are increasingly required for mobile devices and environmentally-conscious manufacturing.

In response to these needs, Epson developed the S1D13L04. The latest addition to Epson’s simple LCD controller series, the S1D13L04 is a low-cost, low-power solution that provides the essential functions of a display controller.
The S1D13L04, which supports panel resolutions ranging from QVGA to XGA, is ideal for displays used in industrial equipment, medical instruments, measuring equipment, office equipment, home automation systems, and a host of other products.

The S1D13L04 uses external SDRAM as a display frame buffer and addresses up to a maximum of 16 megabytes. It is equipped with 16-bit direct/ indirect and serial interfaces which offer flexible interfacing with a CPU. Display functions include multiple windows, alpha blending^*2, transparency, gamma correction^*3, pseudo color expansion, mirror, and 180-degree rotation functions. Images can be displayed in the main window as well as in overlaid picture-in-picture windows (PIP1 and PIP2).

^*1 A type of active-matrix liquid crystal display that uses thin-film transistors (TFTs). They are widely used for displays on products such as PCs and LCD TVs.

^*2 Alpha-blending: The process of overlaying two images, each with a set transparency, to create a composite image.

^*3 Gamma correction: A process for adjusting the brightness and color of images on a display.

Notes:

1. See the attachment for the features and specifications. (58KB)
