The 16-bit, 12-GSPS AD9162 converter’s best-in-class 2.5-GHz bandwidth exceeds the 1.794-GHz optional future requirement specified by the cable industry’s DOCSIS 3.1 standard by nearly 40 percent. The wider bandwidth affords cable operators the ability to plan next-generation network upgrades and capacity expansions without changing converter designs, which reduces product development time and engineering resources.
The AD9162 converter’s industry-best dynamic range (-82-dBc SFDR at -167-dBm/Hz NSD) allows designers to synthesize signals across a wide frequency spectrum from direct-to-RF up to 6 GHz. In wireless applications, this eliminates an IF-to-RF up-conversion stage and local oscillator generation, reducing base station component count, size and power consumption. The AD9162 supports all wireless communications infrastructure protocols (WCDMA, LTE, LTE-A, point-to-point), enabling advanced multiband and multi-standard radio designs.
Additional Features and Benefits
The AD9162 converter features a 2x interpolator (FIR85) that enables configurations for lower data rates and converter clocking to reduce overall system power and ease filtering requirements. In mix-mode operation, the RF D/A converters can be configured to reconstruct RF carriers in the 2nd and 3rd Nyquist zones up to 7.5 GHz while maintaining exceptional dynamic range.
Product Specification
Product | DDS Frequency Hopping |
Update Rate |
Direct RF Synthesis |
Baseband Mode |
Normal Mode |
Mix Mode |
AD9162 | NA | 12 GSPS | 6 GSPS | DC to 2.5 GHz | DC to 6 GHz | 1.5 to 7.5 GHZ |
Pricing and Availability
Product | Sample Availability |
Full Production |
Price Each Per 1,000 |
Packaging |
AD9162 | Now | Now | $150 | 8 mm x 8 mm CSP-BGA 11 mm x 11 mm CSP BGA |
