Osram presents long-life LED for general lighting

Osconiq S3030 is Osram’s entry into the professional mid-power market. The LED is ideal for use in outdoor and industrial lighting. It offers customers LED lighting of the highest quality and great durability even in extreme operating conditions. The individual components provide flexibility in forward voltage and luminous flux with an exceptional lifetime of 75.000 hours even at high temperatures. Together with an optimized phosphor, lead frame and chip design, the development of the Osconiq S3030 raises LED technology to a new level of performance with an impressive efficiency of 146 lm/W. The 0.2 W applications are especially suitable for linear lighting and fluorescent tube replacement. Overall, Osconiq S3030 achieves competitive values for reliability, lifetime and brightness.

“With Osconiq S3030 we have succeeded in developing an LED that is ideal for professional lighting solutions in outdoor, indoor and industrial applications”, said Wong Kum Yih, Marketing Manager for General Lighting at Osram Opto Semiconductors. “With high-grade materials such as the proven Osram designed sapphire chip and robust silicone, we have taken the stability of LED lighting to the next level. In addition to outstanding lifetime values, our customers also benefit from superior quality and improved performance.”

Osconiq S3030 is available in two versions (CRI 70 or 80) with a power rating of 1.0 W at 6 V and a luminous flux of 138 to 148 lm. The footprint of both versions is comparatively small at 3.0 mm x 3.0 m x 3.0 mm. The color temperature ranges from 2,700 to 6,500 K. The beam angle of 120° and the extremely low thermal resistance of around 8.9 K/W make the LED ideal for outdoor lighting. In addition to the technical improvements, Osconiq S3030 features professional grade materials such as high-quality long-life packaging subcomponents and proprietary coatings. These materials have been validated by extensive robustness testing under extreme overload conditions. What’s more, the EMC (epoxy molding compound) lead frame material provides the basis for much longer life and better reliability than conventional PPA and PCT materials.
