Latest solutions for different power electronics applications on display: new X-GaN gate driver, LDPGS as the next thermal management solution, the latest capacitors and resistors for high power applications, as well as new power choke coils in 12×12 case size for high current automotive applications.
Nuremberg, Germany – May 10, 2016 – Panasonic Automotive & Industrial Systems Europe showcases its technology lineup for PCIM (Power Conversion Intelligent Motion) 2016, taking place May 10 – 12 in Nuremberg, Germany. At Stand 429 in Hall 6 the company is highlighting industry-leading innovations — including passive components, semiconductors and thermal management solutions — that provide increased efficiency and reliability for a wide range of applications.
As GaN moves from an innovative technology to mainstream production, Panasonic exhibits real and exciting applications that harness the power of their gallium nitride power transistors. The newly released X-GaN(TM) gate driver optimized for high frequency switching unlocks the full performance of the X-GaN transistor while keeping design efforts to a minimum. A fine control is possible (0.5% – 99.5% @ 50kHz). It benefits from built-in precise current source optimized for GiT transistors and built-in negative voltage source. The company also shows some GaN application examples: GaN-based compact power supply units and a GaN-based inverter for motors. Also a GaN evaluation environment, GaN power devices, power modules (GaN and SiC based), as well as a bidirectional AC/DC converter for power storage systems (SiC application example) features on the stand.
In addition, Panasonic presents its prototype of assist robots that applies X-GaN technologies at PCIM for the first time in Europe, to showcase one of its applications. Power assist suits for industrial use have been developed by Activelink Co., Ltd., one of Panasonic’s in-house venture companies. Panasonic has applied inverter technologies of X-GaN to ActiveLink’s assist suit equipped with motors that assist human body mechanics.
Panasonic showcasts with LDPGS the next step for the Pyrolytic Highly Oriented Graphite Sheet (PGS) portfolio which is the thinnest thermal solution in the world with an industry leading thermal conductivity of up to 1950 W/m K which is 5 times higher than common materials like copper. LDPGS (Low Density Pyrolytic Graphite Sheet) has been developed for Thermal Interface Material (TIM) and convinces thanks to lowest thermal resistance, easy handling and due to the fact that it enables highest system reliability. Through its flexibility and ability to be cut in any shape, it allows new solutions for thermal management challenges where space and weight restrictions are critical and conventional solutions like grease are not feasible. LDPGS graphite sheet consists of a 2D carbon matrix with a thickness of only 200 µm, which effectively disperses and transfers heat along Z direction, protecting sensitive electronics like server units, IGBT modules or common inventors from damage.
Further passive components from Panasonic on display at PCIM Europe 2016 include a wide variety of the company’s latest capacitors and resistors. Featured resistors include current sensing resistors which are designed for low resistance to minimize power consumption. Panasonic offers a wide range of components in many different case sizes (0402 to 2512) and many resistance values. The metal plate technology (ERJM-series) and special constructions makes the parts suitable for harsh environments while maintaining their high reliability. The double-sided resistor element technology (ERJxBW-series) and wide terminal technology (ERJA, ERJB-series) is ideal for high power applications. The company’s current sensing resistors correspond to AEC-Q200 and therefore are well suited for all different kinds of automotive applications. Further technical details include a large power dissipation capability, soft termination to reduce the risk of solder joint cracking, high ESD resistance, and high pulse resistance.
Featured capacitors include Panasonic’s industry leading range of film capacitors and hybrid capacitors. The high reliability and high performance of the film capacitors facilitates the design of custom made modules that enable safe and robust designs for DC-link operation. The two lines of hybrid capacitors mark a perfect mixture of solid polymer and liquid electrolyte which allows high ripple current in very small sized capacitors. Stable characteristics over the whole frequency range and low ESR even at low temperatures support high power applications.
In order to cover the market demand and application’s requirements, Panasonic have developed a new Power choke coil technology (high power SMD in 12×12 case size ETQP8MxxxJFA.). Based on metal powder, the panasonic High Power SMD is suitable for high ripple current application (e.g. Engine System, Start& Stop system, Steering system, etc…). Panasonic High Power SMD is not only suitable as replacement for rod core coil, but also suitable for downsizing. Instead of using 13×13, 15×15 or 17×17 case size, Panasonic can offer its High power SMD in 12×12 case size with same or even better electrical characteristics. Therefore this will lead also to reduce the size of the component and reduce the space on the PCB. With its low DCR characteristics, low power dissipation can be achieved with Panasonic High Power SMD.
For further product information, please visit: https://eu.industrial.panasonic.com/
Panasonic Automotive & Industrial Systems Europe (PAISEU) is a company that provides unparalleled expertise to leading car manufacturers, industrial customers and OEMs. It researches, develops, manufactures and supplies key electronic components, devices and modules up to complete solutions across a broad range of industries; and provides production equipment which builds the manufacturing lines of global corporations. Globally, Panasonic’s Automotive & Industrial Systems is responsible for over one third of Panasonic’s overall revenue.
