Coilcraft- MAG Pro DC-DC Optimizer

• New! Visualizes and enables comparison of inductor efficiency and total loss vs load current across different inductors for better design optimization
• Uses measured inductor data for off-the-shelf inductors. Not just theory.
• Finds optimal solutions for all inductance values. Not limited to pre-chosen inductance & ripple current
• Visualizes I_L waveform, inductor total loss (AC&DC), L vs. I, ΔT vs. current, and more

Coilcraft’s  DC-DC Optimizer starts with power converter parameters, calculates the needed inductor specifications, identifies off-the-shelf part numbers, and provides side-by-side performance analysis. A powerful unique feature of this tool is the option to calculate performance for thousands of standard inductors without pre-selecting the ripple current and thus limiting the inductance range that may be considered. This powerful calculation breaks down old rule-of-thumb barriers and shows new optimal inductor choices for smaller size and better performance. The tool can identify optimal inductors for buck, boost, and buck-boost converters. With just a few clicks you can go from Vin/Vout converter requirements to an inductor selection complete with losses and saturation analysis all based on verified inductor data. This provides you with the fastest design cycle and the most confidence in the inductor selection.

For users who already know the inductor specification or wish to proceed directly to analyze may consider Coilcraft’s Power Inductor Finder and Analyzer

Link for Optimizer: https://www.coilcraft.com/en-us/tools/dc-dc-optimizer/#/

Contact: Avi Elia, Sales Engineer, 0547532262
